Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361]

SKU: AUMHP000104

Original price was: $3,999.95.Current price is: $2,995.00.

The 40cm x 50cm Dual Electric Heat Press is a Heat Press Machine for sublimation, transfer printing and compatible blank production. Key features include Electric motor system delivers consistent, automated pressure without the need for an air compressor.

Out of stock

Notify me when available This item is currently out of stock. Enter the quantity you need and your email address. We will notify you when enough stock is available. Notifications do not reserve stock; the first completed order secures it.

We will only use your email for this notification. Stock is not reserved and may sell before you complete an order.

This machine draws 10.42A, must be on its own circuit and the circuit breaker must be 12A or 16A.

Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Description

📖 What to know about the 40cm x 50cm Dual Electric Heat Press

With an electric dual platen, you can quickly produce garments with accuracy and reliability. The completely automated system allows you to run a timed pressing system with movement delays, pressing delays and total print run counters.

This heat press does NOT have precise pressure adjustment, as it is a purpose-built machine for Direct to Film Transfers and high-pressure required sublimation blanks.

The press can be run manually by pressing right shift to move the heating pressure platen to the right and left shift to move left. If set up correctly with movement delays, this press will continuously move back and forth in a timed manner under its own power until it has been told to stop or it reaches its production counter.

Complete with a digital screen, all settings and timings are set with the digital controller for easy adjustments.

Well constructed with a metal frame, consistent, reliable results, best value for money heat presses in Australia.

Our heat press machines are designed for printing textiles, t-shirts, mouse pads, puzzles, ceramic tiles and other flat surface items by using the flex, flocking, transfer printing paper, sublimation, DTF, etc.

Our heat press machines are covered by a 12-month return-to-base warranty. We will either repair or replace your heat press if required, but we have less than a 2% failure rate. Items like heating belt elements for mug presses are not covered under warranty and are considered a consumable.

For user manuals and more detail, Click Here

Packaged with foam, plastic bags and moisture absorbing satchels, please keep out of reach of children.

📋 Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Features

Electric motor system delivers consistent, automated pressure without the need for an air compressor. Dual 40 x 50cm platens support large-format garments and high-coverage designs. Motorised system automatically opens and closes the press for consistent and hands-free operation. Dual platen system allows you to load one garment while the other is pressing, significantly increasing production efficiency. Engineered for uniform thermal distribution and pressure consistency across demanding production runs. Digital temperature and timer controls allow precise adjustment for consistent pressing results. Heavy-duty construction and dual workflow make it ideal for commercial and high-volume environments. Set press timings, dwell cycles, and total press counts to run a fully automated production workflow with minimal operator input.

📏 Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Dimensions

Product Dimensions

Product Length83.00 Cm (+/- 5%)
Product Width94.00 Cm (+/- 5%)
Product Height73.00 Cm (+/- 5%)
Product Weight144.00 Kg (+/- 5%)

Shipping Dimensions

Shipping Length107.00 Cm (+/- 5%)
Shipping Width87.00 Cm (+/- 5%)
Shipping Height85.00 Cm (+/- 5%)
Shipping Weight152.00 Kg (+/- 5%)

📋 Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Includes

1 x 40cm x 50cm Dual Electric Heat Press 1 x Power Cord 2 x Press Pads

📋 Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Specifications

🎨 Colours

PrimaryGreen
SecondaryBlack
AdditionalSilver
AdditionalRed

🧱 Materials

PrimaryMetal
SecondaryPlastic
AdditionalFoam
AdditionalRubber

🔌 Electrical Specifications

Plug Type10A
Amps10.42
Watts2500
Volts240
Hertz50hz

👤 Age and Usage

Age RangeAdult
Adult ProductNo

📋 Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361] Design

Electric Automatic Movement

Ajust the time and temp and wait time until it moves tot he next platten, it will repeat the time and temp and return to the next platten, and repeat for the set amount of repeats. Can be operated manually or automatic.

Strong Structure

Built with strength and durability in mind, this machine is a tank!

📘 Product Instructions

Prepare Your Workspace and Materials

Set up your heat press on a stable, heat-resistant surface in a well-ventilated area. Gather your materials: the substrate (e.g., t-shirt or mug), transfer paper with your printed design, heat-resistant tape, and protective sheets like Teflon or butcher paper. Ensure your design is mirrored if needed for sublimation.

Set Temperature, Time, and Pressure

Plug in your heat press and turn it on. Refer to the product's recommended settings (found in our user manuals or product descriptions on printgeek.com.au). Typical ranges:Temperature: 180–200°C (356–392°F) for most sublimation items.Time: 30–60 seconds for fabrics; 180–240 seconds for mugs.Pressure: Medium to firm, depending on the material—adjust the knob or lever accordingly.Allow the press to preheat fully (usually 5–10 minutes) until it reaches the set temperature.

Position and Press

Place the substrate on the lower platen. Align your transfer paper face down on the item and secure with tape. Cover with a protective sheet to prevent scorching. Close the press firmly and start the timer. Apply even pressure—avoid opening mid-cycle.

Cool and Finish

Once the timer beeps, carefully lift the press (use heat-resistant gloves). Peel the transfer paper while hot for best results (or cool for certain materials). Let the item cool completely before handling or packaging.

Safety Tips

Always wear protective gloves and avoid touching hot surfaces.Unplug when not in use.For detailed settings per product, check our heat press user manuals at printgeek.com.au/heat-press-user-manuals.If you're new, practice on scraps to perfect your technique.For high-quality heat presses and supplies, browse our collection at Print Geek Australia. Questions? Contact our team for expert advice!

🎬 Videos about Dual Electric Sliding Heat Press 16 x 20 Inches 40 x 50 Cm [AP2361]

▶️ No Current Video

No current videos are available for this product.

▶ Visit our YouTube Channel

Subscribe to be notified of new videos as they are released.

🛡️ Warranty & Returns

12 month return to base warranty, please see link for more information.

Warranty length: 12 months

View Return to Base Warranty

Warranty coverage is subject to product condition, correct use, manufacturer terms and the warranty conditions listed on the linked page.
