Sale!

Samsung Galaxy Note 9 Aluminium Insert Only

Name: Print Geek Group Pty Ltd
Price range: $

Original price was: $2.00.Current price is: $0.95.

-53%

Replacement insert to suit the Samsung Galaxy Note 9 TPU/PC phone case blank sold by Print Geek Australia. NOTE: ALUMINIUM INSERT ONLY

5 in stock

📖 What to know about the Galaxy Note 9 Insert

This insert is a replacement insert for the cases that Sublimation Supplies sell, they will not fit most other cases, it allows you to either trial prints or replace a failed sublimation case blank, we suggest for first time case sublimators to purchase 1 extra insert just in case an error occurs.

NOTICE: Phone case not included

Useful Links

Click here to find out more about How to sublimate

📋 Galaxy Note 9 Insert Features

Designed as an exact match to the phone case, these inserts provide a seamless replacement option and are perfect for testing designs. ✓

High-definition sublimation coating ensures crisp image transfer, bold colour depth, and smooth, even coverage. ✓

The bright white base helps colours appear brighter and more accurate once printed. ✓

Perfectly flat and silky smooth, delivering a premium, flawless result every time. ✓

Perfect for full customisation, allowing you to reproduce photos, text, and intricate designs with outstanding clarity. ✓

Precision cut-outs allow easy access to buttons, ports and cameras. ✓

📋 Galaxy Note 9 Insert Dimensions

📏 Product Dimensions

Length:	15.60 Cm (+/- 5%)
Width:	7.00 Cm (+/- 5%)
Height:	0.05 Cm (+/- 5%)
Weight:	0.01 Kg (+/- 5%)

📦 Shipping Dimensions

Length:	15.40 Cm (+/- 5%)
Width:	6.80 Cm (+/- 5%)
Height:	0.01 Cm (+/- 5%)
Weight:	0.01 Kg (+/- 5%)

📋 Galaxy Note 9 Insert Includes

1 x Galaxy Note 9 Insert ✓

📋 Galaxy Note 9 Insert Specifications

🎨 Colours

Primary	White
Secondary	Silver
Additional	Aluminium

🧱 Materials

Primary

Aluminium

📄 Substrate Specifications

Substrate Colour	White
Substrate Material	Aluminium
Substrate Finish	Gloss

👤 Age and Usage

Age Range	Adult
Adult Product	No

📋 Galaxy Note 9 Insert Design

Perfect Insert Alignment

Our sublimation phone case inserts are engineered for a perfect fit inside the recessed back of the case, ensuring the artwork aligns cleanly with the camera cut-outs and edge contours. Once applied, the insert sits securely without lifting, gaps, or shifting, offering a premium professional finish that enhances both the look and durability of the phone case. Designed specifically for seamless sublimation printing, these inserts help you produce high-quality custom cases with accurate alignment, vibrant colour results, and long-lasting adhesion — ideal for retail-ready personalised phone accessories.

🎨 Print Areas

Print Area 1 Length	156.00 mm (+/- 5%)
Print Area 1 Width	70.00 mm (+/- 5%)

👤 Suggested Bleed

Bleed Left	2.00 mm (+/- 5%)
Bleed Right	2.00 mm (+/- 5%)
Bleed Top	2.00 mm (+/- 5%)
Bleed Bottom	2.00 mm (+/- 5%)

⬇️ Download Design Templates

PSD

JPG

PDF

♨️ How to sublimate a Galaxy Note 9 Insert

📋 Materials Needed

Sublimation printer and sublimation ink
Sublimation paper
Heat-resistant tape

Flat Heat Press

Galaxy Note 9 Insert (Substrate)

🔥 Flat Heat Press Settings

Temperature Min:	180°C
Temperature Max:	200°C
Time Min:	60 Seconds
Time Max:	80 Seconds
Pressure:	High

(Tip: Different presses vary—start at 190°C for 70 seconds and adjust if needed.)

📝 Preparation

For templates, Mock-ups and image size required, please refer to the Design tab.

Print your design, mirror your image.

Remove the protective cover from the sublimation surface.

Clean the substrate printing surface using a microfiber cloth or lint brush to remove dust, oils or lint. (As per substrate)

Place the printed image face up and align the subatrate to the centre of the print.

Secure the edges using heat-resistant tape to prevent movement.

🛠️ Flat Heat Press Pressing

Place a sheet of protective paper on the press.
If this is your first press of the day, make sure you do a pre-press at the suggested heat press settings and bring all materials up to temperature.
Flip the substrate holding the taped areas to secure.

Place the substrate into the press sublimation coating face down, away from the heating element.

Cover with another sheet of protective paper.
Press at listed Heat Press Settings Above.

❄️ Cooling and Assembly

Carefully remove the substrate from the press (it will be hot).
Peel off the sublimation paper while the substrate is warm for best results.
Allow the substrate to cool completely.

Remove the adhesive backing from the Phone Case Cover.

Align and affix the aluminium insert firmly onto the Phone Case Cover.

✅ Tips for Best Results

Ensure full edge-to-edge coverage in your design to avoid white borders (ensure bleed is sufficient).
If colours look dull, increase time by 5 seconds or pressure slightly.
If the coating looks yellowed, your temperature is too high or time too long.
Store substrate in a clean, dry, dust-free area before printing.

Warm the adhesive on the case by hovering the heat press over the case after removing the cover for 10–20 seconds before applying the insert. (Not Included)

Additional information

Weight	0.01 kg
Dimensions	15.4 × 6.8 × 0.001 cm

🎬 Videos about Galaxy Note 9 Insert

▶️ No Current Video

No current videos are available for this product.

▶️ Visit our YouTube Channel

Subscribe to be notified of new videos as they are released.

📖 Warranty/Returns for the Galaxy Note 9 Insert

While the upmost care is taken with handling items, we do not cover the odd minor blemish which will be covered with a darker print. Please visit the link below in regards to returns or exchanges.

Warranty/Returns Link

To find out more about the warranty/returns policy for this item Click Here.
